1. No preload is required.
2. All steel construction for external impact resistance.
3. High-strength, cold-formed, stamped steel construction makes it lighter in weight yet impact resistant forlonger life.
4. Open frame design provides access for easy cleaning and inspection.
5. 360° degree handle rotation with short stroke to ratchet loads.
6. Rubber grip handle for a better comfortable operation,even without glove.
7. Easy free chaining operation.
| Model | Safety Load | No. of falls | Chain dia. | Load chain | Standard Lift | Dimension (mm) | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| a | b | c | d | H | ||||||
| HR-075 | 0.75 T | 1 | 6.3 mm | 80 Grade | 1.5 m | 148 | 128 | 37 | 256 | 295 |
| HR-10 | 1 T | 1 | 6.3 mm | 80 Grade | 1.5 m | 148 | 128 | 45 | 256 | 310 |
| HR-15 | 1.5 T | 1 | 7.1 mm | 100 Grade | 1.5 m | 163 | 148 | 47 | 368 | 335 |
| HR-30 | 3 T | 1 | 9 mm | 100 Grade | 1.5 m | 191 | 181 | 62 | 368 | 405 |
| HR-60 | 6 T | 2 | 9 mm | 100 Grade | 1.5 m | 191 | 244 | 78 | 368 | 550 |
