1. Alloy steel chain grade 100 (25% stronger than grade 80).
2. Hooks with deformation indicators.
3. Simple load chain guide system(horizontal operation o.k).
4. Fully enclosed brake system.
5. Superior rubber grip.
6. Every chain block is operationally tested to 150% of therated
capacity and issue an individual test certificatewith serial
number.
7. Minimum breaking load is 4 times of rated capacity.
8. complied with EN 13157.
| Model | Safety Load | No. of falls | Length | Load Chain Dia. | Proof Load | Dimension (mm) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | H | D | L | ||||||
| KT-075T | 0.75 T | 1 | 1.5 m | 5.6 x 17 mm | 11.3 kN | 140 | 88 | 122 | 39 | 280 | 266 |
| KT-1.5T | 1.5 T | 1 | 1.5 m | 7.4 x 21 mm | 22.5 kN | 167 | 107 | 142 | 49 | 350 | 414 |
| KT-3T | 6 T | 1 | 1.5 m | 9 x 27 mm | 45 kN | 188 | 113 | 185 | 67 | 420 | 414 |
| KT-6T | 6 T | 2 | 1.5 m | 9 x 27 mm | 90 kN | 188 | 113 | 239 | 78 | 570 | 414 |
